Tq340/35y Type Casing Tong (wite back tong)

JIANGSU YOUYAO PETROLEUM MACHINERY CO., LTD.
  • Manufacturing Process:CNC Milling
  • Surface Treatment:Without Processing
  • Operation Pressure:Atmospheric Pressure
  • Material:Plastic
  • Transport Package:4 1,2", 5", 5 1,2", 6 5,8", 7", 8 5,8", 9 5,8", 10
  • Specification:4 -1,2", -13 5,8"

Base Info

  • Model NO.:TQ340,35Y
  • Trademark:YOUYAO
  • Origin:China
  • HS Code:8413910000
  • Production Capacity:100 Sets Per Month

Description

| Drilling equipment >> Casing Tong >> TQ340/35Y type casing tong(wite back tong)



Apply to the dumping of oilfield casing, operating efficiency, significantly reduce labour intensity, and can improve the quality of deduction. The casing tong has the following characteristics:
1, open type, the best cut Path Design;
2, brake band brake, using upper and lower Fuzheng institutions;
3, hydraulic, a total of two tranches speed, gear used Guadang;
4. Back with matching tongs, forceps used to back cards bear the corresponding coupling;
4, with torque table, matching torque control system, display, record and control torque deduction.
Technical parameters are as follows:
1.Adaptation of:
Lord clamp cards 4 1/2", 5", 5 1/2", 6 5/8", 7", 8 5/8", 9 5/8", 10 3/4", 13 3/8"Case of
Back clamp cards 4 1/2", 5", 5 1/2", 6 5/8", 7", 8 5/8", 9 5/8", 10 3/4", 13 3/8",Case Pipe coupling
2, rated pressure: 14MPa (2030 psi)
3, Rated Oil Supply: 120Lpm
4, the output torque: high-grade rated twisting 4.8kN. m  (3569ft-lbs)  low-grade rated torque 35 kN.m (26026 ft-lbs)
5, the greatest speed: high-grade low-grade rated speed of 42 rpm rated to 6 rpm
6, Dimension: 1580 *900*7, Weight: 1100kg (2420 lbs)
