Oilfield Equipment Solids Control System Drilling Tools Shear Pump

Xi'an Boban Oil Tools Co., Ltd.
  • After-sales Service：24,7
  • Warranty：12 Months
  • Certification：ISO 9001:2008
  • Power Source：Electric
  • Operation Pressure：Atmospheric Pressure
  • Material：Cast Steel

Base Info

  • Model NO.：BBSP6535
  • Type：Shear Pump
  • Transport Package：Pallet or Wooden Case
  • Specification：1150× 1100× 1250 , 45x43x49
  • Trademark：BOBAN & OEM
  • Origin：China
  • HS Code：84741000
  • Production Capacity：20 Sets Per Mouth

Description

Basic Info.

Model NO. BBSP6535 Type Shear Pump Transport Package Pallet or Wooden Case Specification 1150× 1100× 1250 / 45x43x49 Trademark BOBAN & OEM Origin China HS Code 84741000 Production Capacity 20 Sets Per Mouth

Product Description

Features and Advantages

Boban JQB Series shearing pump is used to shear, refine, mix polymer, bentonite etc drilling mud material. It can remove "fish eye" help drilling fluid achieve high property for oil drilling. JQB series shearing pump can save over 30% bentonite. It is ideal equipment for oil and gas drilling contractor.


Parameters

ModelSP6545
Inlet Pipe (mm)/(in)DN150 / 6
 Outlet Pipe (mm)/(in)DN125 / 5
Flow (m3/h)120
 Lift (m)/(ft)45 / 148
 Rotating speed (rpm)1900
 Efficiency (%)66
 Cavitation margin (m)/(ft)2.5 / 8
Shaft Power (Kw)  31
Matching Power (Kw)55
Weight (kg)993
External dimension (mm)/(in)990×977×1434
/ 39x38x56
