• Model NO.：GARDNER DENVER,GD,EMSCO,OILWELL,TSC,BOMCO,MP-10
• Condition：New
• Transport Package：Container
• Specification：API#5, API#6, API7#, API8#
• Trademark：UPET
• Origin：China
• HS Code：8413910000
• Production Capacity：50000 PCS,Year

We manufacture and offer 5 different styles of valves & seats as per API standard to fit your

drilling needs, suiting to almost all popular mud pumps in the world. The stem guided valve and

seat and the wing guided valve and full open seat offers many advantages for today's higher

pressures and faster drilling operations: The Stem Guided valve and seat and the Wing Guided

valve and full open seat offers many advantages for today's higher pressures and faster drilling

operations.

Stem-guided valve & Tri-arm seat
Features- greater fluid flow than four-arm seats, as well as it features an extra wide metal to

metal seal on the valve flange, . The serrated upper surface on the valve gives a longer non-

breathing seal between valve body and insert while the rigid seat cross-arms give greater

strength and positive sealing. The strong, thick, valve knock off nut holds the insert tightly

reducing flex and breathing which lessens the chance of foreign matter getting between valve

and insert.

Stem-guided valve & Cross-arm seat
Features: An extra wide metal to metal seal on the valve flange. The serrated upper surface on

the valve gives a longer non-breathing seal between valve body and insert while the rigid seat

cross-arms give greater strength and positive sealing.
The strong, thick, valve knock off nut holds the insert tightly reducing flex and breathing which

lessens the chance of foreign matter getting between valve and insert.

Three-wing guided valve & Full open seat
Three-wing guided valves and full open seats features greater fluid flow than four-wing valves,

the unibody forged valve features greater strength than traditional welded-wing valve.

Innovative unibody valve design eliminates snap rings, plates or keepers providing.

Four-wing guided valve & Full open seat
We offer two style of Four-wing guided valves and full open seats which feature greater fluid

flow through the full open seat. The full open seat provides easier valve maintenance and seat

pulling, in valve-over- valve fluid ends.

Innovative unibody Four-wing guided valve & Full open
Seat valve design eliminates snap rings, plates or keepers providing reduced maintenance by

snap-on valve inserts and easy installation. This combination will handle lost circulation material

better than most conventional style valves and seats while the seating angle greatly improves

flow characteristics and the heavy-duty load bearing capacity greatly improves service life.

The unibody forged Four-wing guided valve & Full open
Seat features greater strength than traditional welded-wing valve. Innovative unibody valve

design eliminates snap rings, plates or keepers providing reduced maintenance by snap-on

valve inserts and easy installation.

Mud Pump Manufactures and Models include:

Brewster Mud Pumps
B-550 | B-750 | B-1000 | 1100T | B-1300

Continental Emsco Mud Pumps
FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

Continental Emsco Mud Pumps
GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

Continental Emsco Mud Pumps
PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

Ellis Williams (Luko) Mud Pumps
WW-440 | 14W-400 | 15W-600 | 9W-1000

Gaso Mud Pump
1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

Gardner Denver Mud Pumps
FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL
Ideco Mud Pumps
MM-200 | MM-300 | MM-500 | MM-500F | MM-550

Ideco Mud Pumps
MM-550F | MM-700 | MM-700F | T-500

Ideco Mud Pumps
T-800 | T-1000 | T-1300 | T-1600

National Mud Pumps
C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000
National Mud Pumps
K-280 | K-380 | K-500 | K-500A | K-700A
National Mud Pumps
7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160
Oilwell Mud Pumps
6P-HD | 610-P | 212-P | 214-P | 218-P
Oilwell Mud Pumps
350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT
Oilwell Mud Pumps
A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT
OPI Mud Pumps
350-D | 00-DL | 700-HDL | 1000-HDL
Wheatley Mud Pumps
1036 | 6070 | 7024 | 7036
Wilson Mud Pumps
600 | 900
