• Model NO.：6417-01,6417-06
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84749000
• Production Capacity：500PCS,Month

ModelTRPS703TRPS585-4TRZS703TRZS585Vibration MotionBalanced Elliptical MotionLinear MotionTreatment Capacity130m³/h140m³/h120m³/h130m³/hMotor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4Screen Area2.6m²2.7m²2.6m²2.7m²Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1GDouble Amplitude7mm7mm6mm6mmDeck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°Ex StandardExdIIBt4 / IECEX / A-TEXWeight1630kg1618kg1620kg1600kgDimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mmRemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.





Xi'an TianRui Petroleum Machinery Equipment Company Limited is a professional manufacturer of various oilfield equipments and solid control equipment since 2010, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.

We have almost 11 years experience of the manufacting, design and supply drilling and workover rig in China, more than 30 engineers' team can satisfy all the special requirement of the oilfield products, can design special according the oilfiled situations and customers requirment.



Our products Including below four series with full model types:



• Solid Control: shale shaker, mud cleaner, decanter centrifuge, mud agitator;
• Drilling Bit: rock roller bit,tricone bit,pdc drill bit,single bit,cone bit and hole opener;
• Drilling Equipment Parts: manual tong,elevator,slips,stabilizer;
• Workover Fishing Tools: releasing spear,junk basket, overshot,reversing sub,die collar, fishing tap etc.



 Tag:

drilling fluid equipment,



mud shaker,



shale shaker
