• Model NO.：BBLS584
• Material：Stainless Steel
• Type：Linear
• Transport Package：Pallet or Wooden Case
• Specification：2998*1856*1522,118*73*60
• Trademark：BOBAN & OEM
• Origin：China
• HS Code：0200
• Production Capacity：20 Sets Per Mouth

Basic Info.

Model NO. BBLS584 Material Stainless Steel Type Linear Transport Package Pallet or Wooden Case Specification 2998*1856*1522/118*73*60 Trademark BOBAN & OEM Origin China HS Code 0200 Production Capacity 20 Sets Per Mouth

Product Description

Features
patent electric shaker deck angle adjustable while working, mechancial deck angel adjustable for backup application.
available in common power supply configurations to meet all applicable global electrical standards.
fluid distribution designed to utilize all available screen area, regardless of drilling conditions.

Advantages
Extand screen life
lowers waste volume
require less rig space


Parameters

	LS584
Vibration Motor	Linear Motion
Vibration Motor(kW)/(hp)	2*1.86kw(2*2.5hp)(Martin)
Vibration Strength(G-Force)	7.1(6.5~7.5)
Screen Surface Area(Square meter)/(ft2)	2.7/29
AWD ( °)	-1~+5
Capacity(m3/h)/(GPM)	136~170 /600~750
Screen Type	Pre-tensioned
Screen Dimension(mm)/(in)	585*1165 / 23*46
Screen QTY	4
Weir Height(mm)/(in)	780/30
Machine Dimension: (mm)	2998*1856*1522/118*73*60
Weight(kg)/(lbs)	1925/4245
