Tph400 Tpd600 Fluid End Parts Qpa1000 4" Fluid End P60-40-000

BETTER DRILLING FLUID EQUIPMENT INDUSTRIAL LIMITED
  • Manufacturing Process：Forging
  • Surface Treatment：Sand Blast
  • Operation Pressure：Vacuum
  • Material：Rubber
  • Transport Package：Plywood Case
  • Specification：hard iron

Base Info

  • Trademark：BETTER
  • Origin：China
  • HS Code：84314310
  • Production Capacity：20000 Sets Per Year

Description

TPD600 3" Fluid End Parts List P60-30-000 FLUID-END,3"1P60-30-1052DISCHARGE COVER SEAL,2.875 X 3.5 X 0.3442P60-30-1031GAUGE COVER W/2" 1502 F3P60-34-1041SEAL RING,2",FIG 15024*P60-30-2002DISCHARGE FLANGE ASSY4a*P60-30-2011DISCHARGE FLANGE4bP60-34-2061SEAL,POLYPAK4c000P5692351O-RING,NITRILE 90 DURO #235,PEROXIDE CURED4dP60-34-2144HHN,1"-8NC,L74eP60-34-2154STUD,1"-8NCx3 1/2",L7 FULL STUD4fP60-34-1041SEAL RING,2",FIG 15025P60-34-3111MANIFOLD6X20-08-01012HHCS,.750-10UNCx1.5",GR8,PLATED7P60-30-4012DISCHARGE COVER8P60-30-0046VALVE SPRING9P60-30-0051FLUID CYLINDER,3"10P60-30-0063PLUNGER,3"11P8T00053003PACKING,SPS,ASSY,3.00012P60-30-0073SUCTION VALVE STOP13P60-30-6006VALVE ASSY15P60-30-0086SEAT,VALVE16000P5692443O-RING,NITRILE 90 DURO #244,PEROXIDE CURED17000P5691466O-RING,NITRILE 90 DURO #146,PEROXIDE CURED1870000107353D-RING CVR S&D 2.50-319P60-30-7013SUCTION COVER20P60-30-0115SUCTION COVER RETAINER NUT21P60-34-0124SCREW,TPFS,1"-12UNx11.00"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS22P60-34-0134SCREW,TPFS,1-3/8"-12UNx10.50"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS23P60-30-8000SEAL,SET,ASSY25P06-00-0603NUT,PACKING,3"26X26-02-00924PLUG,PIPE,1/4"-18NPT,HEX SOCKET,PLATED(SAME PART WITH V06-37-872)



TPD600 3 1/2" Fluid End Parts List

 P60-34-000 FLUID-END,3 1/2",ASSY
1P60-34-1053DISCHARGE COVER SEAL
2P61-34-1031GAUGE COVER W/2" 1502 F
3P60-34-1041SEAL RING,2",FIG 1502
4*P61-34-2002DISCHARGE FLANGE ASSY
4a*P61-34-2011DISCHARGE FLANGE, W/2" FIG 1502 F
4bP60-34-2061SEAL,POLYPAK
4c000P5692351O-RING,NITRILE 90 DURO #235,PEROXIDE CURED
4dP60-34-2144HHN,1"-8NC,L7
4eP60-34-2154STUD,1"-8NCx3 1/2",L7 FULL STUD
4fP60-34-1041SEAL RING,2",FIG 1502
5P60-34-3111MANIFOLD
6X20-08-01012HHCS,.750-10UNCx1.5",GR8,PLATED
7P61-34-4012DISCHARGE COVER
8P60-34-0043VALVE SPRING
9P60-34-0051FLUID CYLINDER,3-1/2" TO 4-1/2"
10P60-34-0063PLUNGER,3 1/2"
11P8T00053503PACKING,SPS,ASSY,3.500
12P60-34-0073SUCTION VALVE STOP
13P60-34-6006VALVE ASSY
15P60-34-0086VALVE SEAT,3 1/2",4" & 4-1/2"
16000P5692443O-RING,NITRILE 90 DURO #244,PEROXIDE CURED
17000P5691536O-RING,NITRILE 90 DURO #153,PEROXIDE CURED
18P60-34-7043SUCTION COVER SEAL
19P61-34-7023SUCTION COVER
20P61-34-0115SUCTION COVER RETAINER NUT
21P60-34-0124SCREW,TPFS,1"-12UNx11.00"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
22P60-34-0134SCREW,TPFS,1-3/8"-12UNx10.50"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
23P60-34-8203SEAL,SET,ASSY
24P60-34-0043VALVE SPRING
25P06-00-0633NUT,PACKING,3-1/2"
26X26-02-00924PLUG,PIPE,1/4"-18NPT,HEX SOCKET,PLATED(SAME PART WITH V06-37-872)



TPD600 4" Fluid End Parts List



 P60-40-000 FLUID-END,4"
1P60-34-1053DISCHARGE COVER SEAL
2P61-34-1031GAUGE COVER W/2" 1502 F
3P60-34-1041SEAL RING,2",FIG 1502
4*P61-34-2002DISCHARGE FLANGE ASSY
4a*P61-34-2011DISCHARGE FLANGE, W/2" FIG 1502 F
4bP60-34-2061SEAL,POLYPAK
4c000P5692351O-RING,NITRILE 90 DURO #235,PEROXIDE CURED
4dP60-34-2144HHN,1"-8NC,L7
4eP60-34-2154STUD,1"-8NCx3 1/2",L7 FULL STUD
4fP60-34-1041SEAL RING,2",FIG 1502
5P60-34-3111MANIFOLD
6X20-08-01012HHCS,.750-10UNCx1.5",GR8,PLATED
7P61-34-4012DISCHARGE COVER
8P60-40-0043VALVE SPRING,4"FLUID END,DISCHARGE(SPM TWS600S)
9P60-34-0051FLUID CYLINDER,3-1/2" TO 4-1/2"
10P60-40-0063PLUNGER,4"
11P8T00054003PACKING,SPS,ASSY,4.000
12P60-34-0073SUCTION VALVE STOP
13P60-34-6006VALVE ASSY
15P60-34-0086VALVE SEAT,3 1/2",4" & 4-1/2"
16000P5692443O-RING,NITRILE 90 DURO #244,PEROXIDE CURED
17000P5691536O-RING,NITRILE 90 DURO #153,PEROXIDE CURED
18P60-34-7043SUCTION COVER SEAL
19P61-34-7023SUCTION COVER
20P61-34-0115SUCTION COVER RETAINER NUT
21P60-34-0124SCREW,TPFS,1"-12UNx11.00"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
22P60-34-0134SCREW,TPFS,1-3/8"-12UNx10.50"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
23P60-40-8203SEAL,SET,ASSY
24P60-34-0043VALVE SPRING
25P06-00-0653NUT,PACKING,4"
26X26-02-00924PLUG,PIPE,1/4"-18NPT,HEX SOCKET,PLATED(SAME PART WITH V06-37-872)


TPD600 4 1/2" Fluid End Parts List



 P60-44-000 FLUID-END,4 1/2"
1P60-34-1053DISCHARGE COVER SEAL
2P61-34-1031GAUGE COVER W/2" 1502 F
3P60-34-1041SEAL RING,2",FIG 1502
4*P61-34-2002DISCHARGE FLANGE ASSY
4a*P61-34-2011DISCHARGE FLANGE, W/2" FIG 1502 F
4bP60-34-2061SEAL,POLYPAK
4c000P5692351O-RING,NITRILE 90 DURO #235,PEROXIDE CURED
4dP60-34-2144HHN,1"-8NC,L7
4eP60-34-2154STUD,1"-8NCx3 1/2",L7 FULL STUD
4fP60-34-1041SEAL RING,2",FIG 1502
5P60-34-3111MANIFOLD
6X20-08-01012HHCS,.750-10UNCx1.5",GR8,PLATED
7P61-34-4012DISCHARGE COVER
8P60-44-0043VALVE SPRING
9P60-34-0051FLUID CYLINDER,3-1/2" TO 4-1/2"
10P60-44-0063PLUNGER,4 1/2"
11P8T00054503PACKING,SPS,ASSY,4.500
12P60-34-0073SUCTION VALVE STOP
13P60-34-6006VALVE ASSY
15P60-34-0086VALVE SEAT,3 1/2",4" & 4-1/2"
16000P5692443O-RING,NITRILE 90 DURO #244,PEROXIDE CURED
17000P5691536O-RING,NITRILE 90 DURO #153,PEROXIDE CURED
18P60-34-7043SUCTION COVER SEAL
19P61-34-7023SUCTION COVER
20P61-34-0115SUCTION COVER RETAINER NUT
21P60-34-0124SCREW,TPFS,1"-12UNx11.00"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
22P60-34-0134SCREW,TPFS,1-3/8"-12UNx10.50"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
23P60-44-8203SEAL,SET,ASSY
24P60-34-0043VALVE SPRING
25P06-00-0583NUT,PACKING,4-1/2"
26X26-02-00924PLUG,PIPE,1/4"-18NPT,HEX SOCKET,PLATED(SAME PART WITH V06-37-872)


QPA1000 4" Fluid End Parts List



 P60-40-000 FLUID-END,4"
1P60-34-10510DISCHARGE COVER SEAL
2P61-34-1031GAUGE COVER W/2" 1502 F
3P60-34-1041SEAL RING,2",FIG 1502
4*P64-34-2002DISCHARGE FLANGE ASSY
4a*P64-34-2011DISCHARGE FLANGE, W/2" FIG 1502 F
4bP60-34-2061SEAL,POLYPAK
4c000P5692351O-RING,NITRILE 90 DURO #235,PEROXIDE CURED
4dP60-34-2145HHN,1"-8NC,L7
4eP60-34-2155STUD,1"-8NCx3 1/2",L7 FULL STUD
4fP60-34-1041SEAL RING,2",FIG 1502
5P60-34-3111MANIFOLD
6X20-08-01020HHCS,.750-10UNCx1.5",GR8,PLATED
7P61-34-4014DISCHARGE COVER
8P60-40-0045VALVE SPRING,4"FLUID END,DISCHARGE(SPM TWS600S)
9P64-34-0051FLUID CYLINDER,3-1/2" TO 4-1/2"
10P60-40-0065PLUNGER,4"
11P8T00054005PACKING,SPS,ASSY,4.000
12P60-34-0075SUCTION VALVE STOP
13P60-34-60010VALVE ASSY
15P60-34-00810VALVE SEAT,3 1/2",4" & 4-1/2"
16000P5692445O-RING,NITRILE 90 DURO #244,PEROXIDE CURED
17000P56915310O-RING,NITRILE 90 DURO #153,PEROXIDE CURED
18P60-34-7045SUCTION COVER SEAL
19P61-34-7025SUCTION COVER
20P61-34-0119SUCTION COVER RETAINER NUT
21P60-34-0124SCREW,TPFS,1"-12UNx11.00"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
22P60-34-0138SCREW,TPFS,1-3/8"-12UNx10.50"LG,HIGH TORQUE FLANGE,GRADE 120M,ROLLED THREADS
23P60-34-0045VALVE SPRING
24P60-40-8205SEAL,SET,ASSY
25P06-00-0655NUT,PACKING,4"
26X26-02-00940PLUG,PIPE,1/4"-18NPT,HEX SOCKET,PLATED(SAME PART WITH V06-37-872)
