• Colour：Customner Requirement
• Transport Package：Container
• Specification：ZP175,205,275,375,520
• Trademark：UPET
• Origin：China
• HS Code：8431431000
• Production Capacity：180 Sets,Year

Overview Product Description

These series of rotary bushing are suitable for API standard rotary slips, drill collar slips, casing slips,insert bowls and roller bushings, with two structures: solid body and split body. Two drive types are available: pin driven and square driven. It is designed and manufactured according to API Spec 7K "Specification for Drilling Equipment". These series of rotary bushing are suitable for API standard rotary slips, drill collar slips, casing slips,insert bowls and roller bushings, with two structures: solid body and split body. Two drive types are available: pin driven and square driven. It is designed and manufactured according to API Spec 7K "Specification for Drilling Equipment"

The technicals of the casing bushing

ModelRotary table size (in)Insert bowlTubulars OD(in)MSS(solid)17 1/2~2310112 3/8~7 5/8Extended 10242 3/8~8 5/827 1/210222 3/8~7 5/8Extended 10252 3/8~8 5/810269 5/8~10 3/4200211 3/4~13 3/8MSS(Split)17 1/2~27 1/2/2 3/8~7 5/8MSPC(Solid)20 1/2~22 1/218092 3/8~8 5/819029 5/8~10 3/4Master bushing 1805-111 3/4~13 3/8Master bushing 1933311 3/4~13 3/823~27 1/218102 3/8~8 5/819049 5/8~10 3/4190311 3/4~13 3/8MDSP(Split)17 1/2~20 1/2/2 3/8~8 5/8MSP(Split)27 1/2/2 3/8~8 5/8MPCH37 1/266082 3/8~8 5/866099 5/8~10 3/4661011 3/4~13 3/849 1/2MPCH 37 1/22 3/8~13 3/8

Casing bushing:

1.Model: CU,CB,CUL

2.Type:solid casing bushing

3.Standard: API Spec 7K

4.tubulars OD: 2-3/8~20 inch

5. applicable rotary talbe size : 17-1/2~49-1/2 inch

Casing Bushing and Insert Bowls

We provide trustworthy bushings for use in all rotary drilling and casing applications. We offer a time tested and industry proven line of bushings to accommodate both primary and backup rotary drilling applications. Our supply includes a wide range of casing bushings, master bushings and roller Kelly bushings to accommodate virtually any combination of rotary table and tubular.

The casing bushings we manufactured include type CU, CUL, CB and insert bowls, they can handle casing from 9-5/8 to 30 inch. Type CU and CUL are solid bushings; type CB are split bushings.

CU, CUL and CB casing bushings are inserted directly into the rotary table and ensure that the casing being run is perfectly aligned with the center of the hole. All of the bushings accept the bowls of different sizes to accommodate a wide range of casing.

The technicals of the casing bushing

Rotary Table SizeBushing Typecasing size OD(in)23/8-85/895/8-103/4113/4-133/816185/8-20242630171/2 or 201/2CUBushing 3102Bushing 3102Bushing3102/////Insert Bowl 1809Insert Bowl 190226 or 271/2CULBushing 3103Bushing 3103Bushing 3103Bushing3103Bushing 3103///Insert Bowl 3105+1809Insert Bowl 3105+1902Insert Bowl 3105Insert Bowl 3104 271/2CBBushing 6695Bushing 6695Bushing6695Bushing6695Bushing 6695///Insert Bowl 6126+6115Insert Bowl 6126+6114Insert Bowl 6126Insert Bowl 6127371/2Bushing 10187Bushing 10187Bushing10187Bushing10187Bushing 10187Bushing
11253Bushing
16454Bushing
11763
 Insert Bowl 6126+6115Insert Bowl 6126+6114Insert Bowl 6126Insert Bowl 6127Detailed Photos
