- Model NO.：Spring stabilizer
- Centralizers Type：Hinged Non Welded Bow Spring Centralizer
- APP：Well Drilling
- Sample：Avaliable
- OEM：Avaliable
- Transport Package：Wooden Case
- Specification：4-1,2" to 20"
- Trademark：ZS
- Origin：Henan
- Production Capacity：50000 Piece,Pieces Per Month
| Non Welded Centralizer Specification(mm) |
| Specification | Bow Type | Hoop Ring Internal Diameter(d) | Hoop Ring Wall Thickness(T) | Hoop Ring Height(H) | Total Length(L) | Max. O.D. Size
| Bow Spring(N) |
| 5-1/2"*8-1/2" | Double Bow | 142-148 | 3-5 | 90-120 | 650±50 | 225±5 | 5 |
| 7"*9-5/8" | Double Bow | 181-186 | 3-5 | 90-120 | 650±50 | 255±5 | 6 |
| 7"*8-1/2" | Single Bow | 181-186 | 3-5 | 90-120 | 650±50 | 235±5 | 6 |
| 8-5/8"*12-1/4" | Single Bow | 223-228 | 3-5 | 90-120 | 650±50 | 330±5 | 8 |
| 9-5/8"*12-1/4" | Single Bow | 250-255 | 3-5 | 90-120 | 650±50 | 330±5 | 8 |
| 10-3/4"*12-1/4" | Single Bow | 274-276 | 3-5 | 90-120 | 650±50 | 330±5 | 9 |
| 13-3/8"*17-1/2" | Single Bow | 342-347 | 3-5 | 90-120 | 650±50 | 450±5 | 11 |
| 18-5/8"*24" | Single Bow | 476±1 | 3-5 | 90-120 | 600±50 | 610±5 | 12 |
| 20"*26" | Single Bow | 510±1 | 3-5 | 90-120 | 600±50 | 660±5 | 12 |
| Welded Centralizer Specification(mm) |
| 5-1/2"*8-1/2" | Single Bow | 142-148 | 5-7 | 50-60 | 650±50 | 225±5 | 5 |
| 5-1/2"*8-1/2" | Double Bow | 142-148 | 5-7 | 50-60 | 650±50 | 225±5 | 5 |
| 5-1/2"*8-1/2" | Cyclone Single Bow | 142-148 | 5-7 | 50-60 | 650±50 | 225±5 | 6 |
| 6"*8-1/2" | Double Bow | 154-118 | 5-7 | 50-60 | 650±50 | 225±5 | 5 |
| 13-3/8"*17-1/2" | Single Bow | 342-349 | 8 | 50-60 | 580 | 450±5 | 6 |
| 20"*26" | Single Bow | 510-518 | 8 | 50-60 | 650±50 | 670±5 | 10 |
