Petroleum Equipment & Machinery

Drilling Equipment Solids Control Vertical Cutting Dryer

Xi'an Boban Oil Tools Co., Ltd.
  • After-sales Service:24,7
  • Warranty:12 Months
  • Manufacturing Process:Casting
  • Surface Treatment:Polishing
  • Operation Pressure:Atmospheric Pressure
  • Material:Cast Steel

Base Info

  • Model NO.:BBVC-1000
  • Transport Package:Pallet or Wooden Case
  • Specification:2780x2080x2450mm
  • Trademark:Boban & OMG
  • Origin:China
  • HS Code:84741000
  • Production Capacity:25 Sets Per Month

Description

  Model                  BBVC-1000                  BBVC-800         Inner diameter of  bowl                   950mm                  750mm                  Bowl length                   450mm                   Bowl speed                  820r/min                 820r/min                 Screen speed                  810r/min                Separation factor                      360                     410                     Capacity                     60t/h                  25-40t/h            OOC after treatment                     ≤5%                     ≤5%                  Screen size                   0.38mm           0.20mm/0.25mm/                     0.38mm/0.50mm                  Power spec                 380V/50Hz                380V/50Hz             Main motor power                    55kW                    37kW              Oil pump power                    120W                    120W            Overall dimensions  3820mm×3360mm×5900mm         2300×1650×1100mm                     Weight                   9200kg                   3200 kg
