• Model NO.：FP-5.1,2
• Flow Sub：R4″
• Size：1840×800×510mm
• Weight：140kg
• Transport Package：Wooden Case or Pallet
• Specification：5.1,2"
• Trademark：TR Solids Control
• Origin：Xi′an, China
• HS Code：84749000
• Production Capacity：100PCS,Month

Model

FP-5.1/2

FP-5.1/2II

Applicable
range

mm

88.9mm - 177.8mm

in

3.1/2" - 7"

Drill pipe size

5.1/2"
Body-body

5"
Body-body

4.1/2"
Body-body

4"
Body-body

3.1/2"
Body-body

5.1/2"
Body-coupling

5"
Body-coupling

4.1/2"
Body-coupling

4"
Body-coupling

3.1/2"
Body-coupling

Flow sub

R4″

NPT3

Size

mm

1840×800×510

1125×700×640

in

73×32×20

44×27.5×25

Weight

kg

140

100

lb

308

220

Key Features & Benefi

·   Occupies minimal space in its park position

·   Seal kits are suitable to the pipe diameter, reducing spills to a minimum extend - plus seal kits can be changed quickly

·   Hydraulically remote controlled or manually operated

·   Integrated mud return line or seperate mud return line via hoses

·   Environmentally friendly due to significantly less mud spills on the drill floor

·   Remote operation - the crew is kept out of harm's way during mud bucket operation

·   Automatic operation from a remote control console or drillers cabin with adjustable slewing speeds

·   Reduces crew work and fatigue caused by continuous handling of a manual mud buckets

·   The design avoids all pinch point

·   Fully integratable into a zone management system to prevent collisions with other equipment in motion
