Drilling Fluids Dwm System High- Efficiency Mud Separate Desilter
Xi'an Boban Oil Tools Co., Ltd.- After-sales Service：24,7
- Warranty：12 Months
- Manufacturing Process：Casting
- Surface Treatment：Spray-Paint
- Operation Pressure：Atmospheric Pressure
- Material：Stainless Steel
Base Info
- Model NO.：BBQJ300*2 , 1
- Transport Package：Pallet or Wooden Case
- Specification：1630× 1136× 2313
- Trademark：Boban & OMG
- Origin：China
- HS Code：84741000
- Production Capacity：25 Sets Per Month
Description
Model
BBQJ300×2 / 1
BBQJ250×2 / 1
Cyclone conic cylinder diameter
300 mm
250 mm
Working Pressure
0.2~0.45 MPa
0.2~0.45 MPa
Capacity
240 / 120 m3/h
200 / 100 m3/h
Screen size
1240×585 mm
1240×585 mm
Screen spec
120-200
120-200
Inlet diameter
6″
6″
Outlet diameter
8″
8″
Power
0.5 kW
0.5 kW
Weight
780/680 kg
740/640 kg
Dimension
1630×1136×2313
1630×1136×2250
