Pin Drive Type 5-1/4′′ Hexagon Kelly Drive Bushing
UPET GROUP CO., LTD.- Manufacturing Process:Forging
- Surface Treatment:Galvanized
- Operation Pressure:Atmospheric Pressure
- Material:Cast Steel
- Warranty:1 Year
- Application:Oilfield
Base Info
- Model NO.:5-1,4′′
- Colour:Customer Requirement
- Transport Package:Container
- Specification:3′′, 3 1,2′′, 4′′, 4 1,2′′, 5′′
- Trademark:UPET
- Origin:China
- HS Code:73061900
- Production Capacity:200000 PCS,Year
Description
We provide trustworthy bushings for use in all rotary drilling and casing applications. We offer a time tested and industry proven line of bushings to accommodate both primary and backup rotary drilling applications. Our supply includes a wide range of casing bushings, master bushings and roller Kelly bushings to accommodate virtually any combination of rotary table and tubular.
Features:
1.Roller kelly bushing is a necessary tool for drilling.
2.It is to drive kelly spinner by matching with master bushing. Through rotating of four rollers, the friction between rollers and kelly pipe is reduced and service life is extended.
3. For different sizes of kelly pipe and hexagonal pipe only need to change corresponding rollers. To connect with rotary table, there are two transmission styles (square drive and pin drive).
4.The product is designed and manufactured according to API Spec 7K "Specification for Drill Equipment".
Technical Specification and Parameter:
Model
HDS
27-HDP
20-HDP
MDS
20-MDP
17-MDP
LDS
Type
Heavy
Medium
Light
Max. torque
N.m
32365
22555
13729
ft.lbf
23871
16636
10126
Drive Mode
Square
Pin
Square
Pin
Square
Square
mm
76.2~152.4
63.5~133.35
63.5~133.35
in
3~6
21/2~51/4
21/2~51/4
Hex
mm
76.2~152.4
76.2~107.95
76.2~107.95
in
3~6
3~41/4
3~41/4
Size
mm
630*630*740
630*630*780
493*493*696
510*510*720
458*458*700
508*508*700
in
24.8*24.8*29.1
24.8*24.8*30.7
19.4*19.4*27.4
20*20*28.3
18*18*27.5
20*20*27.5
Weight
Kg
700
730
670
420
460
340
400
lb
1540
1610
1470
924
1012
750
808
