Oilfield Drilling Tool 9 5/8" Hydraulic Two Stage Cementing Collar

Puyang Zhongshi Group Co., Ltd.
  • Certification：ISO 9001:2008, ISO, API
  • Surface Treatment：Spray-Paint
  • Material：Carbon Steel
  • Type：DV Collar
  • Use：Well Drilling
  • OEM：Avaliable

Base Info

  • Model NO.：Hydraulic Two Stage Cementing Collar
  • Sample：Avaliable
  • Transport Package：Wooden Case
  • Specification：5 1,2"-13 3,8"
  • Trademark：ZS
  • Origin：Henan

Description

Size, in5 1/2"7"9 5/8"13 3/8"Max O.D., mmΦ170Φ208Φ283Φ381Drill-out I.D., mmΦ122Φ155Φ220Φ315Overall Length, mm1082118212221280Rated Load, t140170210300Sealing Capacity, MPa25252525Opening Pressure, MPa13131314Closing Pressure, MPa5555Lower Sliding Sleeve I.D., mmΦ85Φ115Φ176Φ203Upper Sliding Sleeve I.D., mmΦ95Φ125Φ197Φ285
Introduct
>>Hydraulic stage collar meets the challenges of cementing holes at any angle with a hydraulically opened port system.
>>Stage collar designed specifically for horizontal completion.
>> It is specifically used for Primary cementing in deep vertical or high deviated horizontal-well conditions.
>>It reduces total hydrostatic pressureon weak formations to prevent lost circulation during cementing.
>>Clear surface indications of opening and closing pressures provide safer and more efficient operations.
>>The opening pressure of the stage collar can be adjusted at rig site to meet well requirements, providing operational flexibility.
