Factory Supply Desander Desilter Hydrocyclone for Drilling Fluids Separation
Xi'an Boban Oil Tools Co., Ltd.- After-sales Service:24,7
- Warranty:12 Months
- Certification:ISO 9001:2008
- Power Source:Hydraulic
- Operation Pressure:Atmospheric Pressure
- Material:Polyurethane, Wire,Stainless
Base Info
- Model NO.:BBXLQ
- Type:Desilter
- Core Components:Cyclones
- Color:Gray,Blue,Red,Yellow; Customized
- Diameter:125-500mm
- Transport Package:Wooden Case
- Specification:As per sizes
- Trademark:BOBAN & OEM
- Origin:China
- HS Code:8431431000
- Production Capacity:1000 PCS Per Month
Description
Overview
Product DescriptionSpecifications Diameter(mm) Inlet Pressure(MPa) Capacity(m3/h) Cut Size(μm) FX840 840 0.04-0.15 500-900 74-350 FX710 710 0.04-0.15 400-550 74-250 FX 660 660 0.04-0.15 160-450 74-220 FX610 610 0.04-0.15 200-300 74-200 FX500 500 0.04-0.2 140-240 74-200 FX400 400 0.04-0.2 100-170 74-150 FX350 350 0.04-0.2 70-160 50-150 FX300 300 0.04-0.2 45-90 50-150 FX250 250 0.04-0.3 40-80 40-100 FX200 200 0.04-0.3 25-40 40-100 FX150 150 0.04-0.3 14-35 20-74 FX125 125 0.04-0.3 8-20 20-50 FX100 100 0.04-0.3 8-20 20-50 FX75 75 0.1-0.4 4-10 10-40 FX50 50 0.1-0.4 2-5 7-40 FX25 25 0.1-0.6 0.3-1 5-20 FX10 10 0.1-0.6 0.05-0.1 1-5
Product ParametersHYDROCYCLONE SPECIFICATIONS
