SL225 Swivel for Oil Drilling Rig High Quality

Shandong Beyond Petroleum Equipment Co., Ltd.
  • After-sales Service：1year
  • Warranty：1 Year
  • Certification：API
  • Power Source：Hydraulic
  • Operation Pressure：5000psi
  • Applicable Medium：Mud

Base Info

  • Model NO.：SL225
  • Structure：Vertical
  • Material：Stainless Steel
  • Max.Static Load (Kn)：2250
  • Max. Speed (Rpm)：300
  • Max. Working Pressure (MPa)：35
  • Lower Thread：6 5,8 Reg-Lh
  • Fractured Surface at Bail Bend (mm)：70*120 R60
  • Overall Dimension (mm)：2970*990*980
  • Transport Package：Export Packing
  • Specification：2500kg
  • Trademark：Beyond Petroleum
  • Origin：China

Description

TypeSL225Max. Static load (KN)2250Max. Speed (rpm)300Max. working pressure (Mpa)35Angle between gooseneck central line and vertical line15°Lower thread6 5/8 REG-LHBore size of central pipe (mm)φ75Dia. of wash pipe (mm)φ75Fractured surface at bail bend (mm)70x120  R60Bail bend radiusR115Overall dimension (mm)2970x990x980Weight (kg)2500
