Dynj550-200 Big Torque Rotary Type Make-up and Break-out Machine

Huludao City Liaoxi Petroleum Machine and Tools Factory
  • Certification：ISO
  • Scope of Application：Φ177.8-Φ540 mm
  • Rated Torque：200kn.M
  • Type：Petroleum Drilling Tool & Accessory
  • Usage：Screw-on and Screw-off Machinery
  • Power Type：Electric

Base Info

  • Model NO.：DYNJ550-200
  • Transport Package：Wooden Case
  • Origin：China
  • HS Code：8431431000
  • Production Capacity：6 Sets,Month

Description

Configuration NameTechnical SpecificationsQTYUnitPackingRemarksConsoleComputer torque recorder, saving records, printing curve report1
Set
Wooden cases Hydraulic Power SystemMotor:power 37KW speed1460r/min, Required power:380V,frequency for:50HZ1SetWooden casesHydraulic pump type: Variable plunger pumpTurnbuckle mechanism maximum working pressure: 26 mpaOil tank capacity:1540LMake up/ breat out host machineTailstockPipe dia.:Φ177.8-540mm 1SetWooden casesWalking speed :adjustableThe clamping accuracy: ≤ 1.5 mm
spinning wrenchPipe dia.:Φ177.8-540mm1
SetMake-up torque range:0.6-200KN.mBreak-out torque range:0.6-200KN.mTurnbuckle Angle: 360 hovering at any positionThe clamping accuracy: ≤ 1.5 mmBaseLength:5.5m1Set
