Mud Pump Parts Piston Rod

HEBEI XINHUAFA PETROLEUM MACHINERY CO., LTD.
  • Manufacturing Process：Forging
  • Surface Treatment：Spray-Paint
  • Operation Pressure：Vacuum
  • Material：Cast Steel
  • Cetification：API
  • Application：Piston Pump

Base Info

  • Model NO.：All
  • Specifications：60 to 300mm
  • Advantage：Durable
  • Tensile Strength：>610MPa
  • Name：Mud Pump Parts Piston Rod
  • Package：Standard
  • MOQ：3
  • Port：Tianjin
  • Model：F Series,3nb Series,etc
  • Theory：Centrifugal Pump
  • Transport Package：Wooden Box and Sea Shipment
  • Specification：standard
  • Trademark：xinhuafa
  • Origin：Cn
  • HS Code：841391000
  • Production Capacity：50000sets,Per Year

Description

Name

Technical parameters

Remarks

Diameter

Φ9-Φ200



Diameter tolerance

F6-f9

Customized

Thickness of chromium coating (μm)

Δ=0.015-0.05

Customized

Surface roughness

Ra0.2-Ra0.4



Cylindricity  (mm)

≤0.01



Straightness (mm)

≤0.15/1000



Surface hardness

HB220-HB260



Neutral salt spray test (NSS)

Class 9,120h

 Refer to GB6458-86 standard, equivalent to ISO3768-1976



They are available for these types as follow:

BrandTypeEmscoF-500F-650F-800F-1000FA-1300FB-1300FA-1600FB-1600FC-1300FC-1300    Gardener DenverPZ-7PZ-8PZ-9PZ-10PZ-11  National7-P-508-P-809-P-10010-P-13012-P-160  IdecoT-800T-1000T-1300T-1600   OilwellA-350A-560A-650A-850A-1100A-1400A-1700UNBT950950L11801180L   HongHua & Bomco & Lanzhou3NB-5003NB-8003NB-10003NB-13003NB-16003NB-2200 F-500F-800F-1000F-1300F-1600F-2200
