Xq89 Tubing Power Tong and Spare Parts Insert Dies

Dongying Lake Petroleum Technology Co., Ltd.
  • After-sales Service：No Overseas Service Provided
  • Warranty：1 Year
  • Certification：ISO 9001:2000, API
  • Power Source：Hydraulic
  • Operation Pressure：Customization
  • Applicable Medium：Pipe

Base Info

  • Model NO.：All model
  • Structure：Not Applicable
  • Material：Alloy
  • Certificates：API ISO
  • Transport Package：Standard Export Packing
  • Specification：refer to product description
  • Trademark：Lake
  • Origin：China
  • HS Code：8431431000
  • Production Capacity：200 Sets Per Month

Description

Overview Product DescriptionFeatures

Product ParametersModelXQ89/3YCXQ114/6YBXQ140/12YA Φ60~Φ89mmΦ73~Φ114mmΦ73~Φ140mmApplication Range of Master TongApplication Range of Backup TongΦ89~Φ114mmΦ89~Φ141mmΦ89~Φ154mm     1100N.m1500N.m2600N.mHigh Gear Rated Torque 3000N.m6000N.m12000N.mLow Gear Rated Torque 90 r/min85 r/min72 r/minHigh Gear Rotation Speed 30 r/min20 r/min14 r/minLow Gear Rotation Speed 10 MPa11 MPa12 MPaRated Operation Pressure 80 L/min100 L/min120 L/minMax. FlowDimension:L×W×H mm650×430×550750×500×6001024×582×539 158 kg1220 kg550 kgWeight(With Backup)Detailed PhotosHow to contact us
