• Model NO.：2-7,8
• Transport Package：Wooden Case
• Specification：2-7,8
• Trademark：zx
• Origin：China
• HS Code：8431431000
• Production Capacity：3000PCS

Basic Info.

Model NO. 2-7/8 Transport Package Wooden Case Specification 2-7/8 Trademark zx Origin China HS Code 8431431000 Production Capacity 3000PCS

Product Description

Downhole Gas Separation /Gas Anchor is designed for the separation of gas from the oil during pumping it by rod pumps. Gas anchors are screwed on the tubing under the pump and it is external suction pipe. To the bottom of anchor is attached muffled by cap pipe tubing, and pump inlet is screwed into the inner suction tube that extends to the bottom (muffled) pipe tubing.



Features
1,Gas separation
2,Production increase
3,Prevents gas locking
4,Pump efficiency and pump rate will be increased

Technical Parameter

Type	LZX-113	LZX-140
Max OD mm	113	140
Max OD of cup mm	132	165
Connection thread type	27/8TBG	27/8TBG
Max length mm	3200	3200
Suitable casing size  in	51/2''	7''

* Other sizes and connections available on request
