Martin Chain Sprockets for Automatic Conveyor Equipment Gearbox Transmission Belt Parts General Hardware Transmission Roller Chain Wheel
Qingdao Star Machine Technology Co., Ltd.- After-sales Service：7*24hours
- Warranty：1 Year
- Manufacturing Process：Forging
- Surface Treatment：Polishing
- Operation Pressure：Atmospheric Pressure
- Material：Alloy
Base Info
- Model NO.：C2122 C2042
- Standard or Nonstandard：Standard
- Application：Motor, Electric Cars, Machinery, Marine, Toy
- Hardness：Hardened Tooth Surface
- Manufacturing Method：Rolling Gear
- Toothed Portion Shape：Spur Gear
- Type：Circular Gear
- Colors：Nature, Black, Blue, Znic Plating (Galvanization)
- Average Tensile Strength：17.5kn-1550kn
- Usage：Sugar Machinery, Woodworking Machinery
- Certification：ISO90001, SGS
- Packaging：Carton Cases, Gunny Bags, Pallet or Wooden Box
- Special Treatment：Heat Treatment, Polishing and So on
- Use on：Stereo Garage, Flour Machinery, Harvester
- Use for：Steel Mills,Automatic Production Line
- Using：Automatic Coating Line, Chemical Machinery
- Transport Package：According to Customer′s Request
- Specification：simples, duplex, triplex, quadruplex
- Trademark：SMCC or Customize
- Origin：Qingdao China
- HS Code：7315119000
- Production Capacity：10000000meters,Year
Description
ASME/ANSI B29.1-2011 Roller Chain Standard SizesSize Pitch Maximum Roller Diameter Minimum Ultimate Tensile Strength Measuring Load 25 0.250 in (6.35 mm) 0.130 in (3.30 mm) 780 lb (350 kg) 18 lb (8.2 kg) 35 0.375 in (9.53 mm) 0.200 in (5.08 mm) 1,760 lb (800 kg) 18 lb (8.2 kg) 41 0.500 in (12.70 mm) 0.306 in (7.77 mm) 1,500 lb (680 kg) 18 lb (8.2 kg) 40 0.500 in (12.70 mm) 0.312 in (7.92 mm) 3,125 lb (1,417 kg) 31 lb (14 kg) 50 0.625 in (15.88 mm) 0.400 in (10.16 mm) 4,880 lb (2,210 kg) 49 lb (22 kg) 60 0.750 in (19.05 mm) 0.469 in (11.91 mm) 7,030 lb (3,190 kg) 70 lb (32 kg) 80 1.000 in (25.40 mm) 0.625 in (15.88 mm) 12,500 lb (5,700 kg) 125 lb (57 kg) 100 1.250 in (31.75 mm) 0.750 in (19.05 mm) 19,531 lb (8,859 kg) 195 lb (88 kg) 120 1.500 in (38.10 mm) 0.875 in (22.23 mm) 28,125 lb (12,757 kg) 281 lb (127 kg) 140 1.750 in (44.45 mm) 1.000 in (25.40 mm) 38,280 lb (17,360 kg) 383 lb (174 kg) 160 2.000 in (50.80 mm) 1.125 in (28.58 mm) 50,000 lb (23,000 kg) 500 lb (230 kg) 180 2.250 in (57.15 mm) 1.460 in (37.08 mm) 63,280 lb (28,700 kg) 633 lb (287 kg) 200 2.500 in (63.50 mm) 1.562 in (39.67 mm) 78,175 lb (35,460 kg) 781 lb (354 kg) 240 3.000 in (76.20 mm) 1.875 in (47.63 mm) 112,500 lb (51,000 kg) 1,000 lb (450 kg Pitch (inches) Pitch expressed
in eighths ANSI standard
chain number Width (inches) 1⁄4 2⁄8 25 1⁄8 3⁄8 3⁄8 35 3⁄16 1⁄2 4⁄8 41 1⁄4 1⁄2 4⁄8 40 5⁄16 5⁄8 5⁄8 50 3⁄8 3⁄4 6⁄8 60 1⁄2 1 8⁄8 80 5⁄8
For mnemonic purposes, below is another presentation of key dimensions from the same standard, expressed in fractions of an inch (which was part of the thinking behind the choice of preferred numbers in the ANSI standard):
in eighths
chain number
